Characteristic:
1.The plastic housing and pressure bearing parts are made of high-strength engineering plastic, which is dimensionally stable, sturdy and durable.
2.Nominal pressure: 1.6MPa, working temperature: 0.1 ℃ < t ≤+50 ℃.
3.Tested by authoritative departments and found to meet national health standards.
Can be equipped with a high-frequency transmission meter cover
Nominal diameter | Length(mm) | Connection thread | Cover thread |
DN15 | 165 | G3/4B | B82X3/B82X2.5 |
DN20 | 195 | G1B | B82X3/B82X2.5 |
DN25(假) | 225 | G1 1/4B | B82X2.5 |
DN25 | 225 | G1 1/4B | B86X3/B88X3 |
DN32 | 230 | G1 1/2B | B86X3/B88X3 |
DN40 | 245 | G2B | B107X3 |
DN50 | 300 | G2 1/2B | B107X3 |
