Characteristic:
1.The plastic housing and pressure bearing parts are made of high-strength engineering plastic, which is dimensionally stable, sturdy and durable.
2.Nominal pressure: 1.6MPa, working temperature: 0.1 ℃ < t ≤+50 ℃.
3.Tested by authoritative departments and found to meet national health standards.
Nominal diameter | Length(mm) | Connection thread | Cover thread |
DN15 (Internally Adjustable) | 165 | G3/4B | B71X2 |
DN15 (Externally Adjustable) | 165 | G3/4B | B63X2 |
DN20 (Internally Adjustable) | 195 | G1B | B71X2 |
DN20 (Externally Adjustable) | 190 | G1B | B63X2 |
